Hongsheng invites you to visit our factory to purchase the newest, best-selling, affordable, and high-quality 30Kg Medical Waste Incinerator. We are looking forward to working with you.
The 30kg medical waste incinerator is a compact, high-efficiency thermal destruction system specifically designed for small healthcare facilities, clinics, and laboratories. This fully-contained unit provides safe, on-site disposal of biohazardous materials while meeting stringent medical waste treatment standards.
● Capacity: 30kg per cycle (4-6 cycles/day)
● Chamber Dimensions: 600mm × 450mm × 400mm
● Temperature Range:
◎ Primary chamber: 800-950°C
◎ Secondary chamber: 1050-1200°C
● Residence Time: ≥2 seconds in secondary chamber
● System Dimensions: 1.5m × 1.1m × 1.8m
● Weight: 380kg (empty)
● Dual-chamber refractory-lined construction
● Programmable logic controller (PLC) with touchscreen interface
● Automatic fuel modulation (diesel/LPG options)
● Forced air combustion with adjustable flow rates
● Dry scrubber with lime injection (acid gas neutralization)
● High-efficiency particulate air (HEPA) filtration
● Activated carbon adsorption (dioxin/furan control)
● Water-spray quench system
● Automatic door interlocks
● Over-temperature shutdown
● Negative pressure containment
● Emergency cooling system
|
Parameter |
Specification |
|
Cycle Time |
45-60 minutes |
|
Volume Reduction |
≥97% |
|
Ash Residue |
<3% of input |
|
Particulate Matter |
<50mg/Nm³ |
|
CO Emissions |
<100mg/Nm³ |
|
Dioxins/Furans |
<0.1ng TEQ/Nm³ |
● Infectious waste (WHO Category B1)
● Pathological waste
● Sharps (needles, blades)
● Pharmaceutical waste
● Contaminated PPE
● Radioactive waste
● Cytotoxic drugs
● Pressurized containers
● Mercury-containing devices
● Immediate on-site destruction of biohazards
● Eliminates storage and transportation risks
● Continuous operation capability (24/7)
● 60-70% cost savings vs third-party disposal
● Minimal maintenance requirements
● 3-year ROI typical for medium clinics
● Meets WHO guidelines for medical waste treatment
● Complies with EPA Medical Waste Incinerator Standards
● Satisfies EU Directive 2000/76/EC requirements
Space Needs:
● Minimum 3m × 3m dedicated area
● 230V/15A power supply
● Ventilation: 10 air changes/hour
● Fire-rated enclosure recommended
Personnel:
● One trained operator
● Weekly maintenance technician
Daily:
● Ash removal and disposal
● Chamber inspection
● Filter condition check
Weekly:
● Burner nozzle cleaning
● Gasket inspection
● Safety system test
Quarterly:
● Refractory lining evaluation
● Emission control service
● Full system calibration
Facility: Regional Health Clinic
Location: Nairobi, Kenya
Waste Volume: 25kg/day
Implementation Results:
● Eliminated weekly waste collection costs
● Reduced infection control incidents by 35%
● Achieved full regulatory compliance
● 68% cost reduction in first year
|
Method |
Incinerator |
Autoclave |
Chemical |
|
Pathogen Destruction |
100% |
99.9% |
99% |
|
Volume Reduction |
97% |
0% |
30% |
|
Operating Cost/kg |
$0.80 |
$1.20 |
$1.50 |
|
Regulatory Acceptance |
Global |
Limited |
Restricted |
The 30kg medical waste incinerator provides healthcare facilities with:
✔ Complete biohazard destruction on premises
✔ Regulatory-compliant operation meeting international standards
✔ Significant cost savings versus outsourcing
✔ Compact footprint for space-constrained locations
● Rural hospitals and clinics
● Private medical practices
● Laboratory facilities
● Emergency medical services
● Veterinary hospitals
With its combination of advanced thermal destruction technology and comprehensive emission controls, this unit delivers safe, effective medical waste management in a practical, cost-efficient package.
