1000kg Animal Carcass Incinerator

The 1000kg Animal Carcass Incinerator is a heavy-duty, industrial-scale waste management solution designed for large farms, slaughterhouses, veterinary hospitals, and government disease control centers. With a massive 1-ton per cycle capacity, this system ensures complete sterilization of biohazardous materials while maintaining strict environmental compliance.

Key Highlights

✔ High-Volume Processing – Handles 1000kg per batch (suitable for cattle, horses, and livestock herds)

✔ Triple-Chamber Combustion – Ensures 99.99% pathogen destruction

✔ Automated Operation – PLC-controlled with remote monitoring capabilities

✔ Eco-Friendly – Meets EU, EPA, and WHO emission standards

1000kg Animal Carcass Incinerator Technical Specifications

1000kg Animal Carcass Incinerator Core Functional Features

1 Triple-Chamber Combustion System

· Primary Chamber: Pre-heats and decomposes carcasses at 900°C+

· Secondary Chamber: Afterburns gases at 1100°C–1300°C for complete sterilization

· Tertiary Chamber (Optional): Further treats emissions via catalytic converter

2 Advanced Pollution Control

· Wet Scrubber System – Reduces particulates (<30mg/Nm³)

· Activated Carbon Filter – Eliminates dioxins & furans (<0.1ng TEQ/Nm³)

· Cyclone Separator – Removes fly ash before chimney release

3 Automated Control System

· Touchscreen HMI with real-time monitoring of:

o Temperature curves

o Fuel efficiency

o Emission levels

· Remote Access – 4G/WiFi-enabled for off-site supervision

4 Safety Mechanisms

✔ Explosion-proof doors with hydraulic locking

✔ Emergency quench system (500L water reserve)

✔ Flame failure & overheat alarms

1000kg Animal Carcass Incinerator Applications

· Livestock Epidemic Control – Mass disposal during ASF, avian flu, or foot-and-mouth outbreaks

· Municipal Animal Control – Stray animal carcass management

· Meat Processing Plants – High-capacity slaughter waste disposal

· Zoos & Wildlife Reserves – Large animal remains processing

1000kg Animal Carcass Incinerator Operational Workflow

1 Loading Process

· Pre-heat chamber to 600°C (30–45 mins)

· Load carcasses via hydraulic lift system (max 1000kg)

· Seal & pressurize before ignition

2 Combustion Phases

1. Primary Decomposition (2 hrs @ 950°C)

2. Gas Afterburning (1.5 hrs @ 1200°C)

3. Final Oxidation (30 mins @ 800°C)

3 Post-Processing

· Ash collection (<30kg residue per ton)

· Scrubber maintenance (Auto-flush cycle)

· Data logging (Compliance reports auto-generated)

1000kg Animal Carcass Incinerator Competitive Advantages

1 Environmental Compliance

· Meets EU IED, EPA 40 CFR Part 60, and China GB18484

· Near-zero visible emissions with scrubber system

2 Economic Benefits

· 60% lower operating costs vs. outsourcing disposal

· Heat recovery option (up to 100kW thermal output)

3 Durability & Maintenance

· Refractory lining lifespan: 5+ years

· Modular design for easy part replacement

1000kg Animal Carcass Incinerator Installation Requirements

· Foundation: 400mm reinforced concrete (8m×4m)

· Utilities:

o 380V power (20kW)

o Water supply (for scrubber)

o Fuel storage (5000L diesel tank recommended)

· Clearance: 4m around unit for servicing

1000kg Animal Carcass Incinerator Maintenance Protocol

· Daily: Ash removal, nozzle inspection

· Weekly: Scrubber cleaning, pressure checks

· Annual: Full refractory inspection

1000kg Animal Carcass Incinerator Conclusion

The 1000kg Animal Carcass Incinerator is the ultimate solution for large-scale, high-efficiency bio-waste disposal, combining unmatched capacity, regulatory compliance, and smart automation. Ideal for government agencies, large farms, and disaster response teams, this system ensures safe, eco-friendly, and cost-effective carcass management.

For customization (mobile units, continuous feeding, etc.), contact our engineering team.
