The Mobile Animal Carcass Incinerator is a self-contained, transportable waste disposal solution designed for emergency disease outbreaks, remote farms, and disaster response scenarios. Mounted on a heavy-duty trailer with full combustion capabilities, this system provides immediate, on-site carcass disposal without requiring permanent installation.
✔ Fully Mobile – Integrated trailer with ABS braking & road compliance
✔ Rapid Deployment – Operational within 1 hour of arrival
✔ Dual-Chamber Incineration – 800°C–1200°C combustion efficiency
✔ Compact but Powerful – Processes 200–500kg per batch (customizable)
✔ Emission-Compliant – Built-in wet scrubber & cyclone filter
|
Parameter |
Specification |
|
Capacity |
200–500kg/batch (configurable) |
|
Combustion System |
Primary + Secondary Chamber |
|
Temperature Range |
800°C (Primary) / 1100°C (Secondary) |
|
Fuel Type |
Diesel / LPG (dual-fuel option) |
|
Fuel Consumption |
15–25L/hr (diesel) |
|
Trailer Specifications |
|
|
- Chassis |
Tandem axle, GVWR 7,500kg |
|
- Brakes |
Electric-over-hydraulic |
|
- Dimensions |
6000mm × 2200mm × 3000mm |
|
Emission Control |
Wet scrubber + HEPA filter |
|
Power Supply |
12V DC (vehicle) + 220V/5kW generator |
● No Foundation Needed – Fully operational on any flat surface
● Towable by Standard Truck – Compatible with 3.5T+ vehicles
● Fast Setup – <60 minutes from arrival to ignition
● Dual-Chamber Design – Ensures complete sterilization
● Automated Burner Control – Optimizes fuel use
● Low Ash Residue – <5% of original mass
● Integrated Scrubber – Reduces particulates to <50mg/Nm³
● Odor Elimination – Activated carbon filter option
● Compliance – Meets EU & EPA Tier 2 standards
● Automatic Shutdown – Overheat & flame failure protection
● Remote Monitoring – 4G-enabled diagnostics
● Ergonomic Design – Low-profile loading ramp
|
Feature |
Mobile Incinerator |
Fixed Incinerator |
|
Deployment Time |
<1 hour |
2+ weeks (construction) |
|
Installation Cost |
None |
$10,000+ (foundation) |
|
Relocation Flexibility |
Instant |
Impossible |
|
Disaster Response |
Ideal |
Unsuitable |
|
Regulatory Compliance |
Same standards |
Same standards |
● African Swine Fever (ASF) outbreaks – Immediate containment
● Avian Influenza – Rapid poultry disposal
● Mountain ranches – No access to disposal facilities
● Game reserves – Wildlife carcass management
● Disaster zones – Post-flood/earthquake carcass clearance
● Border control – Contraband animal product destruction
1. Site Selection – Level ground, 10m clearance
2. Stabilization – Hydraulic jacks deploy
3. System Check – Fuel/power/water verification
● Loading – Via rear ramp (manual/hoist assist)
● Ignition – Automated preheat to 600°C
● Afterburning – Secondary chamber activation
● Ash Removal – Sealed container storage
● System Flush – Automatic scrubber cleaning
● Eliminates transport costs – No need to move carcasses
● No construction – Saves $15,000+ vs fixed units
● Rental model – $800/day for outbreak response
● Municipal contracts – On-call service agreements
● Daily – Ash removal, nozzle inspection
● Monthly – Refractory lining check
● Annual – Full emission system recertification
● 10+ years with proper maintenance
● Modular upgrades – New filters/burners retrofit
● Location: Eastern Europe
● Units Deployed: 6 mobile incinerators
● Performance:
◎ 42 tons disposed in 14 days
◎ Zero disease spread
◎ 60% cost savings vs burial
The Mobile Animal Carcass Incinerator redefines emergency biosecurity response, combining unmatched flexibility with industrial-grade performance. Its rapid deployment capability and full regulatory compliance make it indispensable for:
● Government disease control teams
● Large-scale farming operations
● Disaster recovery organizations
● High-capacity 500kg models
● Arctic-grade insulated versions
● Military-spec armored units
